Facet Red Top Competition Fuel Pump (6.0 to 8.0 PSI)

£119.58 (+VAT)

SKU: 480532 Categories: , Tags: , ,


The Facet Red Top Fuel Pump is a high performance, lightweight and compact competition fuel pump rated between 6.0 and 8.0 PSI.

An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery.


  • Specification: Competition
  • Pump: 480532E
  • Voltage: 12v
  • Earth: Neg
  • Pressure (Psi): 6.0-8.0
  • Flow: US Gallons/Hr 45
  • Dry Prime Height in Mtrs: 0.6
  • Thread Size: 1/4 npt
  • Operating Temperature: -40º to +180° F (all Models)
  • Average Run Time or MTBF: 6000 hrs
  • Legal Requirements: Certified & Complies With EEC 95/54 Requirements


  • Length: 140mm
  • Height: 54mm
  • Weight: 0.7kg

Please Note: When fitting fuel unions, either wrap PTFE tape around the threads or use Loctite 243 to create a fuel proof seal. The Facet Red Top Competition Fuel Pump is not suitable for use in the aircraft industry.

Estimated dispatch time within 5 working days.

Picture for illustration purposes only. Actual parts may differ slightly in appearance.
