Webcon Universal 24v Fuel Pump (5.0 to 9.0 PSI)

£70.27 (+VAT)

SKU: WFP511 Categories: , Tags: , ,

Description

The Webcon Universal 24v Fuel Pump is rated between 5 and 9 PSI suitable for all Weber carburettor installations. It is a fully sealed unit with steel casing and a zinc plated and yellow passivated finish. This universal 24v fuel pump will suit customers who traditionally have used the small rectangular type pumps but have found them either too noisy or unreliable.

The WFP511 Electric Fuel Pump runs at 0.34 – 0.62 BAR (5.5-9.0 PSI), flows at 90 to 130 litres per hour and is extremely quiet and reliable in operation. This pump is suitable for all higher pressure carburettor installations and may require an additional fuel pressure regulator depending on the exact system pressure required. WFP511 is a “pusher” type pump which is designed to be mounted horizontally near to the base of the fuel tank.

Pump Specification

  • Length: 172mm
  • Diameter: 54mm
  • Inlet: Threaded 1/8 NPT (to take a union)
  • Outlet: Threaded 1/8 NPT (to take a union)
  • Current draw: 5 amps

  • Webcon Universal 24v Fuel Pump (x1)
  • Attached filter (x1)
  • Mounting bracket (x1)
  • Push-On 3/8 O/D fuel pipe unions (x2)
  • Hose clips (x2)
  • 100mm lengths of fuel line (x2)

Please note: This Webcon Universal Fuel Pump is only suitable for negative earth vehicles.

Estimated dispatch time within 5 working days.

Picture for illustration purposes only. Actual parts may differ slightly in appearance.
