Life Racing PDU Keypad

£400.00 (+VAT)

The PDU Keypad by Life Racing is an intelligent and slim membrane panel designed to replace traditional switch panels in a vehicle’s cockpit simplifying wiring and packaging. The PDU Keypad features 20 snap action trans-illuminated buttons in conjunction with 24 programmable LEDs with adjustable brightness control.

Description

The input and output states of the keypad are transmitted / received via CAN 2.0B allowing the system to full flexibility with many ECUs & controllers. Used in conjunction with a Life Racing PDU the keypad blends easily with ‘PDU Setup’ schematic software allowing for quick and easy system integration.

Specification:

Outputs

  • 20 switch outputs over CAN

Inputs

  • 24 configurable LED indicators with adjustable brightness

Interfaces

  • 1 CAN 2.0B interface

Power Supply

  • 6 to 32V input range with reverse polarity protection

Physical

  • 9way D-Type connector
  • Ruggedised plastic moulded case
  • Splash resistant for motorsport fluids
  • Optional M12 cutout holes for additional physical switches
  • Maximum dimensions 170x105x35mm
  • Operating Temperature -25 to 85
  • Total mass ~210g

Sticker Kit

  • A sticker kit is supplied with every keypad in six colours for custom layouts

Warranty and Servicing

  • This equipment comes with a 1 year warranty against manufacturing defects and failures however misuse or damage will not be covered under warranty.

Downloadable Files

life_racing_keypad_data_sheet

Download PDU Keypad Data

Here at Northampton Motorsport, we also offer a full wiring and fitting service as well as engine calibration on our in house Superflow AD30 2 wheel drive chassis dyno. For more information, please contact us and a member of our team would be happy to assist with your enquiry:

Contact Us

Estimated dispatch time within 10 working days.

Picture for illustration purposes only. Actual parts may differ slightly in appearance.
