Description
The Life Racing 13-Key PDU Keypad is a compact keypad based on CAN protocol. It comes equipped with thirteen keys and 2 two push-activated rotary encoders with interchangeable 15 mm inserts. The keypad is water & dust resistant and can be installed both inside and outside the cockpit. RGB LED lights and the ease with which icons can be switched in and out make it possible for the user to customize each key in a wide range of variations.
Our range of Life Racing PDU Keypads come preconfigured ready for use with the range of Life Racing X-Series and XB-Series Power Distributor Units.
Life Racing 13-Key PDU Keypad Specification:
Standard Features
- Reconfigurable keys
- Replaceable icon inserts
- Configurable LED
- High intensity LED status indicators
- LED backlit icons
- Multicolor indicator rings
- Laser etched icons
- Programmable functions (momentary, toggle, scroll…)
- Thousands of stock icons to choose from
- Vertical or horizontal mount
- Protected from inverted polarity
For more technical information, please see the data sheet in the download files below.
Software Features
- Change CAN keypad addresses independently
- Periodic status transmission
- Heartbeat
- Event status transmission
- LED acknowledgement
- Address claim transmission
- CANopen and J1939 communication protocol
- Plug-and-play re-configurability
- Detailed user manuals available
For more technical information, please see the data sheet in the download files below.
Please note: This keyboard comes with 15 plastic laser engraved inserts free of charge. Please see the “Keyboard Inserts” toggle below and leave a note with your order which inserts you require. Additional plastic laser engraved Keyboard Inserts are also available separately.
Keyboard Inserts
PDU Keyboard Insert Diagrams
Download Files
13-Key PDU Keypad Datasheet
Here at Northampton Motorsport, we also offer a full wiring and fitting service as well as engine calibration on our in house Superflow AD30 2 wheel drive chassis dyno. For more information, please contact us and a member of our team would be happy to assist with your enquiry:
Estimated dispatch time within 5 working days.
Picture for illustration purposes only. Actual parts may differ slightly in appearance.
